SU60-3624-2-T
2-Shelf Tubular
SU60-3624-3-T
3-Shelf Tubular
SU60-3624-4-TB
4-Shelf T-Bar
SU60-3624-4-T
4-Shelf Tubular
SU60-3624-4-C
4-Shelf E-Channel
SU60-3624-4-S
4-Shelf Solid
SU60 Cantilever Shelving
Construction
- All Heavy-Duty extruded 6063 Aluminum Alloy
- Available in Heavy Duty Channel, Tubular, T-Bar, or Solid Top Shelves
- 18″, 20″ or 24″ Standard Depths
- Available in 2, 3, or 4 Shelf Configurations
- Adjustable Front Feet for Easy Leveling
- Fully Welded Assembly for Strength
- Custom Sizes Available
Frame
- Uprights are 2″ x 4″ tubing
- Lower support features a gusset-supported 2″ x 4″ x 1/8″ tube and 1.5″ heavy duty square tubing with an adjustable foot
- Custom heights available
Shelves
- Shelves are all aluminum evenly spaced and fully welded to the frame
- Side braces use .25″ x 2″ flat bar
- Shelf cross braces and Tubular shelves use 1.5″ square tubing
- E-Channel shelves use 4″ wide channel
- T-Bar shelves use 2.25″ wide T-Bar
- Solid shelves use .063″ thick sheet metal over a reinforced tubular frame
